Lithium Ion Batteries (LiFePO4) PREMIUM RANGE - TELECO
Ref : T607771
DESCRIPTION :
Teleco's innovative batteries with Lithium ion technology are specially designed for recreational mobile vehicles.
Compared to conventional batteries, they have many advantages:
- They are up to 70% lighter and smaller
- They charge much faster, reaching full charge in less than an hour
- They have a very long duration. It can last up to 5000 discharge cycles, almost 10 times more than a traditional lead-acid battery.
- It is possible to mount them in any position
- They allow the launch of charges with extremely high peaks
- They are safe thanks to the use of Lithium Iron Phosphate Ion technology (LiFePO4 or LFP)
- They are ecological because they use materials with a low impact on the environment: they do not use lead or other harmful materials in accordance with the ROHS directive.
TLI Premium Series
TLI Premium (professional) batteries are distinguished from other lithium batteries on the market by their high energy density: their storage capacity, for the same weight and size, stores much more energy.
TLI Premium batteries contain a sophisticated “Battery Management System” (BMS) that manages the voltage of each cell, both during charging and discharging, thereby increasing its lifespan. The BMS also guarantees protection against breakdowns due to high temperatures, overloads and over-discharges.
Up to 2 batteries can be connected in series and 3 in parallel (of the same capacity).
The characteristics of the BMS are:
Guaranteed quality:
TLI Premium batteries contain a sophisticated “Battery Management System” (BMS) that manages the voltage of each cell, both during charging and discharging, thereby increasing its lifespan. The BMS also guarantees protection against breakdowns due to high temperatures, overloads and over-discharges.
Up to 2 batteries can be connected in series and 3 in parallel (of the same capacity).
The characteristics of the BMS are:
- Integrated CANBUS, CI BUS and Wireless communication
- Integrated safety stall relay
- Autosleep mode function and wakeup button
- Diagnosis and error register
- Control panel (optional) with charge status reading and storage mode entry/exit control
The BMS also guarantees protection against breakdowns due to high temperatures, overloads and over-discharges.
Guaranteed quality:
- Quality control carried out individually for each phase of production
- Selected latest generation components
OPTIONAL :
OLED control panel (only for PREMIUM batteries)
TECHNICAL DATA :
|
Technical characteristics |
TLI Premium 12/104 DIN | TLI Premium 12/120 DIN | TLI Premium 12/150 DIN | TLI Premium 12/200 | |
| Nominal voltage | 12.8V | 12.8V | 12.8V | 12.8V | |
| Ability | 104 Ah | 120 Ah | 150 Ah | 200 Ah | |
| Energy | 1280 Wh | 1536 Wh | 1920 Wh | 2560 Wh | |
| Recommended discharge current @ 25°C | 20 Amp | 24 Amp | 30 Amp | 40 Amp | |
| Maximum continuous discharge current @ 25°C | 100 Amp | 120 Amp | 150 Amp | 200 Amp | |
| Recommended charging current @ 25°C | 20 Amp | 24 Amp | 30 Amp | 40 Amp | |
| Maximum charging current @ 25°C | 100 Amp | 120 Amp | 150 Amp | 200 Amp | |
| Duration | 2000 cycles @ 80% DOD @25°C with 80% residual energy | ||||
| Useful life | 5/7 years | ||||
| Charging voltage | 14.6V | 14.6V | 14.6V | 14.6V | |
| Weight | 10.50 kg | 12.5 kg | 14.5 kg | 23.3Kg | |
| Dimensions [mm] (terminals and handles) | 355x175xH190 DIN L5 | 355x175xH190 DIN L5 | 355x175xH190 DIN L5 | 521x238xH218 | |
| Thick headed | SAE Automative | SAE Automative | SAE Automative | M8 | |
| Temperature | 0°C / +45°C -20°C / +60°C -10°C / +50°C |
0°C / +45°C -20°C / +60°C -10°C / +50°C |
0°C / +45°C -20°C / +60°C -10°C / +50°C |
0°C / +45°C -20°C / +60°C -10°C / +50°C |
|
| Certifications | IEC62133-2, EN55014-1, EN55014-2, UN38.3, RoHs, CE Conformity, UN ECE R10 | ||||
